HURRICANE H70
Flail mowers
30-70 HP (22-52 KW)
540 rpm - Cat. 1 & 2
The Hurricane H70 is a horizontal axis rotary flail mower; its robustness and the quality results it produces make it particularly suitable for contractors or landscape professionals. The transmission is lateral through two CX jagged belts with semi-automatic belt tensionner. The rotor bearings are self-aligning to support greater workloads and increase durability. The cutting height adjustable from a minimum of 20 mm to a maximum of 150 mm is adjusted through the rear roller supplied also with a scraper. The electronically balanced rotor is equipped with a double pivot blade attachment to prevent blade breakage and rotor damage. The rotor may also be equipped with different types of blades depending on the work required and can also be equipped with vertical blades perfect for scarifying lawns with thatch build up.
Model | H70-060 | H70-072 | H70-088 |
|---|---|---|---|
HP | 30-70 | 35-70 | 40-70 |
Working width (cm) | 150 | 180 | 220 |
Overall width (cm) | 180 | 215 | 250 |
Weight Kg | 394 | 433 | 490 |
Ship Kg | 410 | 450 | 505 |
Rotor rpm | 2.080 | 2.080 | 2.080 |
Blades tip speed (m/s) | 43 | 43 | 43 |
Nr of blades | 64 | 80 | 96 |
Cutting height (cm) | 20-150 | 20-150 | 20-150 |
Nr belts & type | 2 CX | 2 CX | 2 CX |
Driveline 1 3/8" | ASAE cat. 4 overrunning clutch | ASAE cat. 4 overrunning clutch | ASAE cat. 4 overrunning clutch |
Reversible hitch for front and rear mounting
Reversible three point hitch for front and rear tractor mounting.
Gearbox by Rotomec
Gearboxes are manufactured by Rotomec and always assembled with top of the line gears, bearings and seals to ensure years of trouble free usage.
Cast iron rotor supports
Our cast iron rotor supports are designed and built in-house and assembled using spherical self-aligning bearings.
Belt shield fender
H70’s are equipped standard with belt shield fenders to protect the drive system from impacts with foreign objects.
Replaceable side skids
All units are delivered with replaceable side skids.
Clockwise rotor rotation
Clockwise rotor rotation allows cut debris to be thrown up and around the rotor and then straight down into the ground, reducing the risk caused by thrown objects.
Specific blades for any application
Only Rotomec offers you the choice of fine cut blades, dethatching blades, reverse “Y” blades, paddle blades or hammers blades allowing the operators to set up the unit specifically for their application.
Dethatching blades (factory installed)
DBD60H70 rotor with dethatching blades for H70-060
DBD72H70 rotor with dethatching blades for H70-072
DBD88H70 rotor with dethatching blades for H70-088
Reverse “Y” blades (factory installed)
YBD60H70 rotor with reverse “Y” blades for H70-060
YBD72H70 rotor with reverse “Y” blades for H70-072
YBD88H70 rotor with reverse “Y” blades for H70-088
Triangular paddle blades (factory installed)
TBD60H70 rotor with triangular paddle blades for H70-060
TBD72H70 rotor with triangular paddle blades for H70-072
TBD88H70 rotor with triangular paddle blades for H70-088
Hammer blades (factory installed)
HBD60H70 rotor with hammer blades for H70-060
HBD72H70 rotor with hammer blades for H70-072
HBD88H70 rotor with hammer blades for H70-088
